| 分类型号/Model Type | HBCO-2003 | HBCO-3003 | HBCO-4003 |
|---|---|---|---|
| 烤盘数量/Trays quantity |
2盘*3层=6盘 2Tray*3Deck=6Tray |
3盘*3层=9盘 3Tray*3Deck=9Tray |
4盘*3层=12盘 4Tray*3Deck=12Tray |
| 收容能力/Tray Direction |
600*400 600*400vertical |
600*400 600*400vertical |
600*400 600*400vertical |
| 外形尺寸/Overall dimension | 1275X958X1625mm | 1650X958X1625mm | 1650X1158X1625mm |
| 电压及功率/Voltage and power |
380V 3P+1N/5KW每层 380V 3P+1N/5KW per deck |
380V 3P+1N/8KW每层 380V 3P+1N/8KW per deck |
380V 3P+1N/9KW每层 380V 3P+1N/9KW per deck |
| 有效温度/Effective Temp |
室温~300度 Room Temp.~300℃ |
室温~300度 Room Temp.~300℃ |
室温~300度 Room Temp.~300℃ |
| 参考事项/Reference matters |
每层买入数及层数要求规格变更可订做 Decks and trays can be customized |
||
